Time Standards

Second hero2

Our Accredited Calibration Services (typical turn-around time 10 working days):

Full IANZ scope is available here. [PDF, 513 KB]  BIPM Calibration Measurement Capabilities available here [PDF, 83 KB].

Service

Range/Conditions

Least Uncertainty

NZ Price (excl GST)

5.91 (a) Frequency meters

1 Hz to 40 GHz

0.001 Hz to 1 Hz (period)

1 x 10-10

1 ns

Please enquire

5.91 (c) Counters

1 Hz to 40 GHz

1 x 10-10

Please enquire



0.001 Hz to 1 Hz (period)

1 ns

Please enquire

5.91 (d) Time interval meters

10 ns to 86400 s

2 ns or 2 x 10-13, whichever is   greatest

Please enquire

5.91 (e) Clocks and watches

5 ns to 1 s

50 ns

Please enquire

5.91 (g) Frequency standards

100 kHz to 10 MHz

2 x 10-13

Please enquire



0.001 Hz to 1 Hz (period)

1 ns

Please enquire

5.91 (h) Time measurement

Time scale difference –  Local   clock vs UTC (MSL)

-1 s to 1 s

2 ns

Please enquire



Time scale difference –         Local clock vs UTC

-1 s to 1 s

50 ns

Please enquire

Waveform Measurement

5.92 (a) Frequency characteristics

1 Hz to 20 MHz

1 in 10-10

Please enquire



0.001 Hz to 1 Hz (period)

1 ns

Please enquire

Waveform Measurement

5.92 (b) Input characteristics

1 V and 3 V

(frequency, f = 1 MHz to   100 MHz)

Pulse risetime (T>5 ns)

(10 mV to 10 V)

0.16 mV/V to 2.6 mV/V

Please enquire



0.005 µs to 1.00 x 106 µs

Q(2 ns, 0.05T), T in s

Please enquire



Pulse amplitude (pulse length > 200 µs) (10 mV, 100 mV, 1 V, 10 V)

0 V to 10 V

(30 μV+ 100Va + 420Vr),

applied voltage Va in V,

voltmeter range Vr in V, values range from 34.2 µV to 5230   µV

Please enquire

Waveform Measurement

5.92 (c) Timing characteristics

10 ns to 100 s

(time difference)

2 ns

Please enquire

Note: All calibrations of instruments will be priced on application.



Contact us



Shipping details:

Measurement Standards Laboratory

Callaghan Innovation

69 Gracefield Road

Lower Hutt 5010

New Zealand

Please be in touch for advice on packing and shipping your equipment to us.



Terms and Conditions:

Prices and typical turn-around times only apply to equipment suitable for calibration using our standard methods and booked in advance.

All other terms and conditions as per our standard work order agreement.



Other IANZ-accredited laboratories with similar services:

Link to a table listing the accredited laboratories with services in this area (updated March 2018 [XLSX, 9.1 KB]).

Full up to date schedules including detailed measurement capabilities are available from IANZ.(external link)
